Month: October 2023

Concept / Idea:

For this assignment, I was inspired by the human body, which I think is one of nature’s greatest wonders. More specifically not by its physical ability, but by its visual potential. What I mean by its visual potential is the ability of the body to grab & maintain attention, visually communicate thought & emotion, and finally visually evoke feelings in others.

With the body there’s this dichotomy, on one side there is this element of commonality or basic core structure, a “skeleton, but on the other side, there’s nuance, subtleties, and little differences that produce individual uniqueness out of extreme diversity. This reminds me a lot of generative art & object-oriented programming & I really wanted to bring both together.

The human body has always been a popular subject in art throughout history, religious, official, and personal & I thought I’d extend that tradition by tackling it in this new medium I’m learning (p5.js)

Logic:

I started out looking at the skeleton of things, trying to come up with what the cookie cutter of a body or face would be like. I divided the body into two different categories, “the headless body” and “the face” because I think each of these has a unique separate visual quality that I wanted to tackle.

The headless body:

This sketch is running in WEBGL, and uses multiple planes placed in the same x & y coordinates but different z coordinates. Initially, the logic behind this was to have planes at different opacities and sizes overlayed / stacked to look like a body.

Scaling up:

Some code I want to highlight:

class Cluster {
  constructor(size,leader) {
    this.mouse = leader;
    this.pos = createVector();
    this.humansList = [new Human(this.mouse)];
    this.size = 10;
    this.type = random(5);
    if (this.type < 1) {
      for (let i = 0; i < this.size; i++) {
        this.humansList.push(new Human(this.humansList[i].handRight));
        this.humansList.push(new Human(this.humansList[i].footRight));
      }
    } else if (this.type < 2) {
      for (let i = 0; i < this.size; i++) {
        this.humansList.push(new Human(this.humansList[i].handRight));
      }
    } else if (this.type < 3) {
      for (let i = 0; i < this.size; i++) {
        this.humansList.push(new Human(this.humansList[i].handRight));
        this.humansList.push(new Human(this.humansList[i].footRight));
        this.humansList.push(new Human(this.humansList[i].hipLeft));
      }
    } else if (this.type < 4) {
      for (let i = 0; i < this.size; i++) {
        this.humansList.push(new Human(this.mouse));
      }
    } else if (this.type < 5) {
      for (let i = 0; i < this.size; i++) {
        if (i < this.size / 2) {
          this.humansList.push(new Human(this.humansList[i].handRight));
          this.humansList.push(new Human(this.humansList[i].handLeft));
        } else {
          this.humansList.push(new Human(this.humansList[i].waist));
          this.humansList.push(new Human(this.humansList[i].shoulderRight));
        }
      }
    }
  }

  render() {
    for (let i = 0; i < this.size; i++) {
      this.humansList[i].render();
    }
  }
}

This code changes how different skeletons are connected to each other based on a random number to create variations that add up and can be seen in a cluster’s shape/movement.

XY Plotter result:

https://drive.google.com/file/d/1gGS_PLDxK66WoZ4x9QCe_aWjSFaERHGQ/view

https://drive.google.com/file/d/14HSQoOd8wGrcDyLQdTE86XtFZQxG5-bO/view

The Face:

Some code I want to highlight:

class Eye {
  constructor() {
    this.pos = createVector(0, 0);
    this.eyeheight = 2 * random(0.6, 1.4);
    this.eyewidth = 10 * random(0.6, 1.2);
    this.r = this.eyeheight;
    this.eyetilt = createVector(random(-0.3, 0.4), random(-0.3, 0.4));
    this.eyeslope = random(1, 1.5);
  }
  render() {
    let multiplier = 10;
    push();
    translate(this.pos.x, this.pos.y);

    fill(255);
    beginShape();

    for (let i = 0; i <= 10; i++) {
      let w = map(i, 0, 10, PI, 0);
      let x = map(i, 0, 10, this.eyewidth / 2, -this.eyewidth / 2);
      let y = this.eyeheight * -sin(w);
      y -= this.eyeheight * sin(w * this.eyeslope) * this.eyetilt.x;

      vertex(x * multiplier, y * multiplier);
    }
    for (let i = 0; i <= 10; i++) {
      let w = map(i, 0, 10, 0, PI);
      let x = map(i, 0, 10, -this.eyewidth / 2, this.eyewidth / 2);
      let y = this.eyeheight * sin(w);
      y -= this.eyeheight * sin(w * this.eyeslope) * this.eyetilt.y;

      vertex(x * multiplier, y * multiplier);
    }

    for (let i = 0; i <= 1; i++) {
      let w = map(i, 0, 10, PI, 0);
      let x = map(i, 0, 10, this.eyewidth / 2, -this.eyewidth / 2);
      let y = this.eyeheight * -sin(w);
      y -= this.eyeheight * sin(w * this.eyeslope) * this.eyetilt.x;

      vertex(x * multiplier, y * multiplier);
    }

    endShape();
    fill(0);
    ellipse(0, 0, this.eyeheight * 15);
    pop();
  }
}

I used different sine waves with phases & amplitudes that change at random and added them together to get different shapes of eyelids.

Scaling up:

Putting them together:

https://youtu.be/Q_Og8rGYwWs

Project Name: Starry Night: A Flowing Painting

A. Concept

This vortex field (or swirling pattern) reminds me of Starry Night by Vincent van Gogh. He created a strong sense of motion, energy, and flux through the use of brushwork and colors.

B. Implementation

Here are the questions to solve to achieve my goal of creating a flowing painting.

1. 1. Swirling movement of the particles
   2. Location of the center
   3. Aesthetics of the strokes

1. Swirling movement of the particles

Firstly, I need to know how to make the particles move in a circular pattern. The particles need to be placed in a flow field that they will be given the velocity according to their position in the field. However, there are different kinds of flow fields: Perlin noise flow fields, vortex flow fields, magnetic flow fields, and so on. I searched the Internet and found a simple way of creating this swirling effect.

Basically, you create a background image showing the distribution of the centers of vortices based on a 2D Perlin noise space. And then you calculate the “pressure differential” around every cell in the grid. That differential vector will point to the center of the vortex, creating an attraction effect to the particles. However, if you rotate every vector by 90 degrees, they will suddenly be turned to some force similar to the “tangential force”. This will magically turn the movement of the particles into a swirling pattern.

Generating a flow field with Perlin noise is a good starting point.

p.s. Here’s a good way of modifying the noise field to make it cleaner and less “noisy”. You can change the parameters in this function called noiseDetail(octave count, falloff).

I also make a 3D noise field that changes through time.

Here are some generative patterns I created from the swirling field:

Lastly, apart from user modification, I also want to “animate” the original painting by Van Gogh. This requires us to take the original painting as the source image.

But how can the computer know the locations of rotation centers of the stars from the painting?

At first, I tried to detect the pixels that have a higher grey scale (brighter). But as you can see, there is only one star that is statistically much brighter than others. This method didn’t work well.

Then I noticed that all the stars are kind of yellow. Therefore, I thought of calculating the Euclidean distance of the RGB value of the pixel with the RGB value of a “standard yellow color”. After some tests, I found that this rule works the best (but still not perfect) anyways I tried…

abs(r-g)<=20;
r: 180 += 20;
g: 165 += 20;
b: 60 += 30;

And then I used the previous renderImg() function to render the base image based on the original painting. You can see that nearly half of the stars have been detected.

Finally, I combined the Perlin noise flow field with this swirling field. Adding some dynamics to the sketch. I also grabbed the original color from the painting and modified the color of the pixels.

Here is the final sketch:

C. Reflection

Program thinking that I gained from this project:

• Combination of forces
  • I combined three kinds of force to affect the velocity (change of position) of my particles: Centripetal force, tangential force, and force due to Perlin noise). The combination adds a lot to the dynamic and aesthetic of the project.
• View buffer canvas as a data source
  • A generative art must have a generative rule. And I think my “generative rule” is the base image placed on a buffer canvas that contains information in every single pixel and tells the particles which direction to go. At first, I placed 2D or 3D Perlin noise images on the buffer canvas, then I allowed the users to add their own stars to this canvas through pixel manipulation, and at last, I extracted information from the original Starry Night painting and used it as a data source.
• Computer vision
  • Of course, I only scratched the surface of “computer vision”. But I believe that my attempt to identify the positions of the stars in the painting through different methods is kind of asking the computer to see and interpret the visual information that humans can easily capture. Through setting rules such as “find pixels with higher greyscale” or “find pixels with smaller RGB distance to the standard yellow”, the computer tries to better detect the positions of the stars with optimized logic.

Unsolved problem:

The biggest challenge I encountered in this project is the pixelDensity() and scaling down and up the image. Since the source image was too large, it needs to be scaled down. Plus I had some buffer canvases, and I often needed to check the index and location of certain pixels and modify them. I used a lot of pixelDensity() function, but it led to some weird results that I couldn’t understand. Therefore I had to change all the pixel densities to 1 to avoid those problems, but it made the resolution of my project less ideal.

Future Improvements:

I’m excited to make the project run in a 3D space where the particles rotate around a sphere. Also, due to the limited capacity of p5js running in a browser, I couldn’t add more particles to make a more appealing effect. So if possible, I will run it in Processing or other faster tools.

Concept:

My midterm project consists of a landscape NFT collection as a combination of my interest in cryptography and generative art. It uses different mathematical and artistic concepts to produce unique nature-related artwork.

Think of NFTs as digital collectibles, like trading cards or unique stamps. When an artist creates a digital artwork, they can “mint” an NFT, which essentially means they create a special, one-of-a-kind digital token associated with that artwork.

In my project, through a GUI, the user can specify the style (acrylic, japanese, animated…) and mint their own NFT. The revolving theme is Nature, as I was inspired by the course’s name “decoding nature”.

Example from OpenSea – NFT marketplace:

View post on imgur.com

Sketch:

For a better experience (Full Screen), use the following link.

Code Walkthrough (Special Functions):

Vintage effect:
In order to get an ancient style, I’m using noise as a primary way to simulate the imperfections and irregularities alongside the random function. i.e. most shapes have irregular edges, cracks, and distortions.

To generate the dots in the corner, I’m using the following:

function displayNoise(){
    strokeWeight(0.5);
    for(let dx = 0; dx < width; dx += random(1, 3)) {
        for(let dy = 0; dy < height; dy += random(1, 3)) {
            let pointX = dx * noise(dy/10);
            let pointY = dy * noise(dx/10);
            if (get(pointX, pointY)[0]==241) {
                stroke(darkColor);
            } else {
                stroke(lightColor);
            }
            point(pointX, pointY);
        }
    }
}

Hand-drawn effect:
To create hand-drawn contours, I’m using sin-waves relying on vertices, noise, and random functions. To get varying amplitudes I’m using the following:

let a = random(-width/2, width/2);
let b = random(-width/2, width/2);
let c = random(2, 4);
let d = random(40, 50);
let e = random(-width/2, width/2);
for (let x = 0; x < width; x ++){
      let y = currY[j];
      y += 10*j*sin(2*dx/j + a);
      y += c*j*sin(5*dx/j + b);
      y += d*j*noise(1.2*dx/j +e);
      y += 1.7*j*noise(10*dx);
    dx+=0.02;
    mountains.push({x,y})
}

As for the vertices and to be able to close the shape in order to be able to fill it later on, I’m using:

beginShape();
vertex(0, height);
for (let i = 0; i < mountains.length; i++) {
    stroke(darkColor);
    vertex(mountains[i].x, mountains[i].y);
}
vertex(width, height);
endShape(CLOSE);

Gradient:
To get a smooth gradient, I’m using the mathematical concept: linear interpolation.

It constructs new data points within the range of a given discrete set data points which are in our case colors.

View post on imgur.com

function applyGradient(x, y, w, h, color1, color2) {
   noFill();
   for (let i = y; i <= y + h; i++) {
      let mid = map(i, y, y + h, 0, 1);
      let clr = lerpColor(color1, color2, mid);
      stroke(clr);
      line(x, i, x + w, i);
   }
}

Granulation and Blur:
To do that, I looped over the canvas pixels and shifted some of them randomly. To further fuzzify the artwork, I rounded the pixels after moving them as well and getting their density.

View post on imgur.com

The code for it is:

function granulateFuzzify(amount) {
    loadPixels();
    let d = pixelDensity();
    let fuzzyPixels = 2;
    let modC = 4 * fuzzyPixels;
    let modW = 4 * width * d;
    let pixelsCount = modW * (height * d);
    for (let i = 0; i < pixelsCount; i += 4) {
        let f = modC + modW;
            if (pixels[i+f]) {
            pixels[i] = round((pixels[i] + pixels[i+f])/2);
                  pixels[i+1] = round((pixels[i+1] + pixels[i+f+1])/2);
                  pixels[i+2] = round((pixels[i+2] + pixels[i+f+2])/2);
            }
        pixels[i] = pixels[i] + random(-amount, amount);
        pixels[i+1] = pixels[i+1] + random(-amount, amount);
        pixels[i+2] = pixels[i+2] + random(-amount, amount);
    }
    updatePixels();
}

Branches generation:
To display realistic branches, I’m alternating the size after each iteration. The branch is drawn using a sequence of circles. I’m using a seed variable called “BranchChance” to add randomness.

display() {
    if (this.size < 2) {
      return false;
    }

    stroke(0);
    fill(0, 0, 0, min(255, 5 * this.size));
    ellipse(this.x, this.y, this.size, this.size);

    this.x += (this.size / 7) * cos(this.angle);
    this.y += (this.size / 7) * sin(this.angle);
    this.size *= random(0.99, 1);
    this.angle += random(-0.05, 0.05);

    if (this.size < 10) {
      this.angle += random(-0.1, 0.1);
    }
    if (this.size < 30) {
      this.angle += random(-0.1, 0.1);
    }

    if (
      (this.size < 10 && random(0, 1) < 0.2 * branchChance) ||
      (this.size > 4 && random(0, 100 / (this.t + 1)) < branchChance)
    ) {
      this.branches.push(new Branch(this.x, this.y, this.angle - PI / 7, this.size, 0));

      this.angle += PI / 7;
      this.t = 0;
    }

    for (let i = this.branches.length - 1; i >= 0; i--) {
      if (!this.branches[i].display()) {
        this.branches.splice(i, 1);
      }
    }
    this.t++;
    return true;
}

Noise Gradient background:
To set a sunset gradient for the canvas with some noise, I’m using ellipses once again as per the following:

function animateSunset(){
  clear();
  let cells = 128;
  let sat = 255;
  let bri = 192;
  let maxNoiseScale = 14;
  let p = 8;
  let cell = width / cells;

  randomSeed(0);

  z2 += 0.001;
  xoffset += 0.001;

  let noisePower = Math.pow(10, Math.log10(maxNoiseScale) / cells);

  let passes = 1;
  for (let z = 1; z <= passes; z++) {
    let cols = cells;
    let rows = cells;
    let noiseScale = noisePower;

    for (let j = -2; j < rows + 15; j++) {
      let y = (j / rows);
      let wy = y * height;

      for (let i = -2; i < cols + 8; i++) {
        let x = (i / cols);
        let wx = x * width;

        // Color
        let q = noise((x * noiseScale) + xoffset, y * noiseScale, z2);
        if (q > 0.5) {
          q = (((Math.pow(((q - 0.5) * 2) - 1, p) - 1) * -1) / 2) + 0.5;
        }
        else {
          q = Math.pow(q * 2, p) / 2;
        }
        q = ((q * 150) + 145) % 255;
        let boxColor = color(q, sat, bri, random(11) + 1);
        fill(boxColor);

        // Draw circle
        let factor = noise(x + xoffset, y, z2) * 23 + 1;
        let diameter = cell * factor;
        ellipse(wx, wy, diameter, diameter);
      }
      noiseScale *= noisePower;
    }
  }
}

Matrix Japanese Text:
The Japanese text represents different nature and life-related quotes that are displayed vertically in a Matrix style. I’m thinking of animating it later.

["風流韻事" // Appreciating nature through elegant pursuits such as poetry, calligraphy and painting
,"柳は緑花は紅" // Willows are green, flowers are crimson; natural state, unspoiled by human touch, nature is beautiful, all things have different natures or characteristics.
,"花鳥風月" // The beauties of nature.
,"旅はまだ途中だぞ" // Our adventure is not done yet
,"前向きにね" // Stay positive
,"雨降って地固まる" // After rain, comes fair weather
,"苦あれば楽あり" // There are hardships and also there are pleasures
,"初心忘るべからず" // Should not forget our original intention
,"浮世憂き世" // Floating world
,"自分の生きる人生を愛せ" // Love the life you are living
,"行雲流水" // Flow as the clouds and water
,"人生は夢だらけ" // Life is full of dreams
,"春になると森は青々としてくるです" // In spring, the forest becomes lush
,"今日の夕焼けはとてもきれいです" // Today's sky is nice and red
,"生き甲斐" // Realisation of what one expects and hopes for in life
];

Challenges:

One of the challenges I have faced is certainly setting the right parameters for the waves to get a somewhat hand-drawn but still realistic set of mountains. It took a lot of experimentation, trial and errors to finally find the right combination. Similarly, for both the gradients to be smooth and match all the components of the artwork, I had to find the right settings for the linear interpolation.

Future Plans:

Incorporate 3D elements using WebGL or other 3D engines.
Allow more customization through the GUI.

Plotter result:

View post on imgur.com

View post on imgur.com

Project Images:

View post on imgur.com

View post on imgur.com

THE FINAL SKETCH

Click on the sketch to generate a new pattern!

MY DESIGN GALLERY

Below are the various different outputs I got from my above sketch:

CONCEPT, INSPIRATION & ARTISTIC VISION

How fascinating would it be to be able to visualize complex math equations into an easy-to-look generative design pattern? Fascinating no!

Math is everywhere around us, in the simplest to most complex of the things, but we don’t always necessarily see it as math. For this midterm project, I wanted to explore mathematical equations and find a way to visualize them using generative art and give them a visible form. But which equation? Or multiple equations? How do I choose?

As a child, I most fondly played with the spirograph set (see pictures below). I would love to draw new designs and patterns through it. Different stencils and position of the pen give different designs.

Some spirographs in nature:

Did you know there are actual math equations that trace the path / locus of these designs? For this project, I wanted to explore the math behind this concept and make generative art within this constraint. Can one equation by itself give rise to multiple varied distinguished designs? What are the the parameters of the equation which give it a certain characteristic? How does changing these parameters affect the design and feel of it?

I did some background research on mathematical equations and spirographs. This website explains the generation of spirographs and the equation behind it in simple terms. I carefully followed and read this as I evolved my idea, tried to code the designs and understood the math behind the visuals I was getting.

THE PROCESS

I started by understanding the physics behind the Spirographs and how they work. So it is essentially a circle within a circle with a point somewhere not in the centre in which you place your pen to create the designs. So I tried to model this using the physics concepts of vectors, position, their rectangular components, oscillation, sine and cosine, we learnt in class.

This was my starting sketch:

Based on some initial calculations that I did:

Here is the code snippet for it which exemplifies this vector behaviour:

translate(width/2, height/2);
circle(0, 0, R); // draw outer bigger circle
center = createVector((R/2-r/2)*cos(angle), (R/2-r/2)*sin(angle)); // center of the inner circle based on my calculations
circle(center.x, center.y, r); // draw inner circle
circle(center.x + r/2*cos(-1*angle), center.y + r/2*sin(-1*angle), 5); // draw the point of drawing --> currently at the boundary of inner circle
angle += 0.1; // increment angle each frame

The above behaviour achieved by simple physics and vectors has the following equation (this I derived myself, but can also be found online):

Going further, I realised it might be easier to get the equation version of the vector’s x and y position to plot it. How will this help? This will help in changing the shapes from circle to say ellipse, hyperbola or from changing the position of the smaller circle to be inside or outside, which would generate interesting and non-generic patterns. This is the time to be creative now!

I experimented with the different parameters like the R, r, t (= angle), and even the functions of sine, cosine, tan, and function enclosed function, along with the changing the sign / direction of vector addition / subtraction to generate different designs.

The multiple iterations and designs I created:

1. Code:

calculate() {
     this.x = (this.r+this.r)*(sin(this.angle))-this.d*0.41*tan((this.R-this.r)/this.r*this.angle*2);
     this.y = (this.R-this.r)*tan(sin(this.angle*1.8))+this.d*0.57*tan((this.R+this.r)/this.r*this.angle);
}

Outcome:

calculate() {
    this.x = (this.r+this.r)*(tan(this.angle))-this.d*0.41*tan((this.R-this.r)/this.r*this.angle*2);
    this.y = (this.R-this.r)*tan(sin(this.angle*1.8))+this.d*0.57*cos((this.R+this.r)/this.r*this.angle);
  }

calculate() {
    this.x = (this.R+this.r)*(cos(this.angle))-this.d*cos((this.R+this.r)/this.r*this.angle);
    this.y = (this.R+this.r)*(sin(this.angle))-this.d*sin((this.R+this.r)/this.r*this.angle);
  }

calculate() {
    this.x = (this.R+this.r)*(cos(this.angle)*2)-this.d*tan((this.R-this.r)/this.r*this.angle/2);
    this.y = (this.R-this.r*2)*(cos(this.angle))+this.d*tan((this.R-this.r)/this.r*this.angle);
  }

It is important to note that I did not have a design in mind that I found the code for. Rather, I took a basic math structure (the base formula) and altered and experimented with it. I wanted to see how far the equation can be taken, pushed beyond its limits, and by changing some of it parameters and characteristics (while keeping basic skeleton of the equation as it is), can we generate complex designs which are completely unexpected for its behaviour? And yes, that happened! I kept on experimenting with the values and functions until I found designs and patterns that I really liked and resonated with me. That is the part of the code I am proud of 🙂

PEN PLOTTING PROCESS

The pen plotting process was an absolutely fun process. I spent hours besides the plotter seeing my designs take form, changing the pen, putting the paper, changing the GoPro battery xD. Completely involved and engaged, I actually plotted 4 of my designs on the plotter and also prepared a matrix of some of my other designs also to be plotted.

Here is the outcome of my designs:

I had to change my code from plotting dots to lines for the pen plotter since we cannot plot a million dots on the plotter. I did this by using the concept of storing the previous position (x, y) of the dot and drawing a line between the previous and the current position each frame.

Here is the code for it:

draw() {
    this.calculate();
    if (dist(this.x, this.y, this.prevX, this.prevY) > width/4) {
      this.prevX = this.x;
      this.prevY = this.y;
    }
    stroke(0,50);
    // point(this.x, this.y); // initially I was just plotting a point at the current x and y
    line(this.x, this.y, this.prevX, this.prevY); // now plotting a line between previous (x, y) and current (x, y)
    this.prevX = this.x;
    this.prevY = this.y;
    this.angle += 0.02;
  }

There is not much difference in the code per say, but the effect and feel of the design definitely changed. I like both the versions! 🙂
Hence, I decided to randomise dots versus dashes in the final sketch.

A peak into the working of the plotter:

Starry Sketches

Starry Sketches is a creative generative art project that generates a range of continuously transforming constellation-like patterns. Different iterations of the project accentuate certain elements, like the feel of the sky and its ambiance, the feel of mesmerization, and the feel of amusement.

Source Code

Concept & Artistic Vision

For my midterm project I began with a route that focused on creating underwater species through creative coding and having each creature evolve into the other in some way or form. This idea was quite interesting and the vision I had in mind was relatively executable. Especially when I came across this project that presented the idea of an evolving circle that led to outcomes similar to what I had envisioned.

Source

To get the exact feel of an underwater environment, I read about sea creatures, their physical characteristics, and their movement manner. I decided finally to focus on four creatures; sea horses, starfish, jellyfish, and octopuses, which each depict unique movement mechanisms. I found that sea horses only hovered in place to move around, whereas starfish crawled and rowed like crabs did, while jellyfish drifted along the currents of the ocean, and octopuses propelled the current and crawled with their tentacles.

Source

Unfortunately, I was not able to go so far with my idea for it felt static despite my attempts to produce a generative piece. This led me to decide to shift my focus away from underwater environment and onto the skies for some sort of inspiration. Given that I began by working on the starfish for my initial idea, I was very keen on incorporating stars in my project, hence I began looking into that field. When reading about stars and looking through. Images for inspiration, I came across star/ zodiac constellations, which are basically stars in close proximity that create “two-dimensional maps for astronomers to find objects and explain their location and for navigators to use stars to determine their position”. However, nowadays, these constellations are often linked with astrology, and are brought up in the context of zodiac signs. The problem with this based on the article is that it has not scientific foundation, for they are just groups of stars that appear close to each other and are named after objects, animals etc.

Source

When reading that the constellations have no exact shapes that confine them and the zodiac constellations have no scientific basis, I felt a sense a freedom for exploration, unlike with the underwater species where I was unable to come up with an abstract representation of already existing creatures. This enabled me to come up with the idea of creating a sketch that constantly generates new constellations by drawing lines based on the proximity of the stars to one another. That way I was able to incorporate the element of the star that I had already began working on while also ensuring that my project was generative and did not appear static.

Coding Translation, Logic, & Challenges

When I began working on the starfish for my underwater project attempt, I was mostly focused on perfecting the shape of the creature and its movement, failing to consider the bigger picture of how the project will translate to a generative piece.

This led me to creating one long ‘for loop’ which, although eventually unused, was a learning process for me that allowed to explore the function of ‘noise’ in so many different ways, whether that be directly on the coordinates, lines, or even colors,  which later came in handy when I worked on the constellations project. Another important take out of this part of my process were ‘nested for loops’ that allowed me to iterate not only through the circumference of a circle but also through its diameter, hence leading to a bunch of nested stars that increase in size with every loop creating one big star.

for(let j=0; j<= 50; j++)
  {
  for (let angle = 0; angle <= TWO_PI; angle += PI/2.5)
{
  let x = centerX + radius * cos(angle);
  let y = centerY + radius * sin(angle) + (3.5 - noise((angle), i / 15) * 7);
  curveVertex(x + noiseX, y + noiseY);
  let x2 = (centerX) + radius2 * cos(angle + HALF_PI / 2.5);
  let y2 = (centerY) + radius2 * sin(angle + HALF_PI / 2.5);
  curveVertex(x2 + noiseX, y2 + noiseY);
}
  //endShape(CLOSE);
  radius-=2;
  radius2-=2;
  }
}

While I was happy with the outcome of the starfish in terms of how it moved and looked, I was not satisfied with the fact that it seemed relatively predictable, and was moving only based on the ‘noise’ that was added to the coordinates, making me feel like I had not incorporated enough from what we have learnt into the project. Hence, moving forward in my process I created a solid plan of what will take place in my sketch.

I started my process simple by creating a class of stars that were of random sizes, positions, velocities, and acceleration, and called a hundred of them to see what the outcome would look like. I immediately realized two main issues with the stars eventually leaving the canvas, and the acceleration increasing nonstop.

class Star
{
  constructor()
  {
    this.position = createVector(random(width), random(height));
    this.size = random(3, 7);
    this.velocity = createVector(random(-0.3, 0.3), random(-0.3, 0.3));
    this.acceleration = createVector(random(-0.01, 0.01), random(-0.01, 0.01));
  }

  update()
  {
    // Update the velocity and position based on acceleration
    this.position.add(this.velocity);
    this.velocity.add(this.acceleration);

   }

  display() {
    let starPoints = random(1, 5);
    let externalRadius = this.size;
    let internalRadius = this.size * 0.4;
    let angle = TWO_PI / starPoints;
    let halfAngle = angle / 2.0;
    fill(255);
    beginShape();
    for (let a = 0; a < TWO_PI; a += angle) {
      let starX = this.position.x + cos(a) * externalRadius;
      let starY = this.position.y + sin(a) * externalRadius;
      vertex(starX, starY);
      starX = this.position.x + cos(a + halfAngle) * internalRadius;
      starY = this.position.y + sin(a + halfAngle) * internalRadius;
      vertex(starX, starY);
    }
    endShape(CLOSE);
  }
}

I added the checkEdges() function like we had previously done with the movers which resolved the issue of the stars flying out of the canvas, however despite adding the ‘limit’ function to the acceleration, the stars continued to accelerate rapidly. I resolved this issue by including an ‘if-statement’ as shown below.

update()
  {
    // Update the velocity and position based on acceleration
    this.position.add(this.velocity);
    // Limit acceleration
    if (this.velocity < 5)
      {
        this.velocity.add(this.acceleration);
      }
   }

Once I had the stars set I began working on the lines which were somewhat a challenge to achieve as envisioned, however I am quite proud of how they came out. I had five different main trials which yielded different results, some of which were actually interesting, but not exactly what I had in mind.

 Attempt 1:

In the first trial, my thought process was simple, I need to draw a line between two stars. So, let the first star be ‘i’ and the second one be ‘j’. Through a ‘for loop’ I thought I was incrementing both the i and j values, however, I came to realize that despite thinking I was incrementing the ‘j’ value, the loop constantly equated its value to one position.

let j;
for (let i = 0; i < stars.length; i++)
{
  j = 0;
  stroke (255);
  line(stars[i].position.x, stars[i].position.y,        stars[j].position.x, stars[j].position.y);
  j++;
}
}

Attempt 2:

For my second trial, I tried to have the line drawn between the star ‘i’, and the star that followed it so, star ‘i + 1’. This also yielded an interesting outcome, but again, the issue was that each star was only connecting  to two other stars, leading to a static outcome.

for (let i = 0; i < stars.length - 1; i++) {
  stroke(255);
  line(stars[i].position.x, stars[i].position.y, stars[i + 1].position.x, stars[i + 1].position.y);
}
}

Attempt 3:

For my third trial, I knew I was on the right track with the previous two attempts, I had to find a ‘j’ value that was an incrementation of the ‘i’ value but still have that looping and incrementing to avoid static connections between the same stars. Inspired by the nested ‘for loops’ that I had initially created for my starfish, I created a nested loop that produced incrementing values for both ‘i’ and ‘j’. The issue with this attempt however was that there were endless connections between all the stars regardless of their positions.

 for (let i = 0; i < stars.length; i++) {
  for (let j = i + 1; j < stars.length; j++) {
      stroke(255);
      line(stars[i].position.x, stars[i].position.y, stars[j].position.x, stars[j].position.y);
  }
}
}

Attempt 4:

In my fourth trial, I built onto the previous trial. I measured the distance between the stars ‘i’ and ‘j’ using the ‘dist’ function and included an ‘if-statement’ that only allowed for a line to be drawn if the stars were in close proximity.

 for (let i = 0; i < stars.length; i++) {

  for (let j = i + 1; j < stars.length; j++) {
    let d = dist(stars[i].position.x, stars[i].position.y, stars[j].position.x, stars[j].position.y);

    if (d < 100) {
      stroke(255);
      line(stars[i].position.x, stars[i].position.y, stars[j].position.x, stars[j].position.y);
    }
  }
}
}

Attempt 5:

By my fourth attempt I was very happy with the outcome, my only issue was that it seemed like it was not representing constellations accurately because each star was connecting to an endless number of stars. I resolved this issue by a count for the lines to the ‘ if statement’ that measured the distance, that way, a line would only be drawn if the stars are in close proximity and if they are not connected to more than two stars.

 for (let i = 0; i < stars.length; i++) {
  let linesConnected = 0; // Initialize the count of lines connected to the current star

  for (let j = i + 1; j < stars.length; j++) {
    let d = dist(stars[i].position.x, stars[i].position.y, stars[j].position.x, stars[j].position.y);

    // Add a condition to check if the number of lines connected to the star is less than 4
    if (d < 100 && linesConnected < 2) {
      stroke(255);
      line(stars[i].position.x, stars[i].position.y, stars[j].position.x, stars[j].position.y);
      linesConnected++; // Increment the count of lines connected to the star
    }
  }
}
}

Moving on from there, I tried to find ways in which I could improve my code and I looked into any further issues that could be resolved. I realized then that my stars overlapped when moving which did not seem realistic to me. I read into that and found that the likelihood of stars overlapping is very small, if not impossible. So, I created a function within the stars that prevents overlapping.

noOverlap()
  {
    // Loops through every star in the stars array
    for (let singleStar of stars)
    {
      // Checks if the singleStar is the same current star called in the sketch
      if (singleStar !== this)
        {
      // If not then measure the distance between this star and the singleStar
        let distance = dist(this.position.x, this.position.y, singleStar.position.x, singleStar.position.y);
      // Making the minimum possible distance between the stars be equal to their sizes combined
        let minDistance = this.size + singleStar.size;
        if (distance < minDistance)
        {
      // Calculate a vector to move this star away from the singleStar
          let repel = createVector(this.position.x - singleStar.position.x, this.position.y - singleStar.position.y);
          repel.normalize();
          repel.mult(0.5); // Adjust the strength of the repulsion
          this.position.add(repel);
        }
      }
    }
  }

This function was one that I explored in one of my previous assignments, it basically loops for every star in the stars array measuring the distance between it and the current ‘this’ star that is being called. It then creates a repulsion force through a vector that subtracts the position of the stars being compared. This force is then added to the position which leads to the stars repelling or moving away from each other.

To further improve my project I looked into more images of constellations to try and find what is missing in my sketch. I realized that in most images the represent constellations the sky is shown with not only the bright stars that create the constellation but also with all the tiny stars that surround. Hence, I decided to create a class that produces tiny stars of varying sizes for the background. This came out really nice especially since the constructor of the class had 10 stars initialized, hence 10 new stars appeared with every frame creating a sparkling effect in the background.

To accentuate the feeling of stargazing and constellations, I decided to change the background to an image of the sky with stars and I added a music track to further draw in the audience.

Source Code

I also attempted to create different versions applying the function of ‘noise’ on multiple elements of my project like I did initially when working on the starfish.

Version 1:

update()
  {
    this.position.x += map(noise(this.noiseX), 0, 1, -2, 2);
    this.position.y += map(noise(this.noiseY), 0, 1, -2, 2);
    this.colors = color(noise(this.noiseColor) * 255);
    this.noiseX += 0.01;
    this.noiseY += 0.01;
    this.noiseColor += 0.01;
    // Update the velocity and position based on acceleration
    this.position.add(this.velocity);
    // to limit acceleration
    if (this.velocity < 5)
      {
        this.velocity.add(this.acceleration);
      }
   }

In this version I added noise to the position of the stars and allowed for that noise to constantly update, leading to a trail behind the stars that made them look somewhat like shooting stars. Because of the looping update of the noise and the unlimited change of position the stars move in rapid speeds and seem to be leaving the canvas despite the bounds.

Version 2:

update()
  {
    this.colors = color(noise(this.noiseColor) * 255);
    this.noiseColor += 0.01;
    // Update the velocity and position based on acceleration
    this.position.add(this.velocity);
    // to limit acceleration
    if (this.velocity < 5)
      {
        this.velocity.add(this.acceleration);
      }
   }

In this version I only added noise to the color of the lines and the stars, and changed the alpha/ opacity which was sufficient to create the starry effect I was looking for with having the stars mov out of the frame as in the previous version.

Version 3 & 4:

In these two versions I added an element of color and changed the background to experiment with the effects that I can achieve.

rainbowColors() {
   // Calculate a color based on noise for the star & lines
   let noiseColorR = noise(this.noiseColor);
   let noiseColorG = noise(this.noiseColor + 1000);
   let noiseColorB = noise(this.noiseColor + 2000);
   let noiseColorA = noise(this.noiseColor + 3000);

     starColor = color(
     Math.round(255 * noiseColorR),
     Math.round(255 * noiseColorG),
     Math.round(255 * noiseColorB),
     Math.round(255 * noiseColorA)
   );
 }

Pen Plotting Process

My process with the pen plotting was luckily simple, although I did struggle initially with exporting the SVG files, however, once I had that figured out the process was relatively smooth.

The issue that arose with the SVG file was from the beginning of my project process when I was working on the starfish. I realized after multiple trials that the problem was not with my method of exporting but rather with the size and elements of the sketch itself. Given that my sketch of the starfish had a great deal of ‘noise’ embedded in its design it made exporting the file into an SVG impossible.

I took that into account when working on my new project with the constellations, and made sure that I worked based on that leaving any ‘noise’ or extensively large elements out of my design for plotting purposes.

In doing so I was able to get an SVG file ready for plotting. The only editing I had to do on Inkscape was remove the background. From there we imported the sketch to the plotter and it began the process which was quite lengthy since I decided to give the star the flexibility to connect to an endless number of nearby stars and I also called 300 stars on the canvas.

Areas of Improvement & Future Work

In terms of improvement and future work, I came across an article that details collisions of stars when reading about whether or not stars overlap. This article mentioned an interesting detail about stars’ collisions explaining that in the rare cases that they collide, if moving at a slow pace they merge to create brighter stars, and if traveling at a fast pace during the collision then they disappear leaving behind only hydrogen gas. I attempted to add this to my sketch however,  I was unsure of how to go about it and since I was somewhat tight on time I decided to leave this as a future addition to the project.

Source

One thing that I realized later could be improved is the way in which the lines appear. Right now the lines immediately connect the stars once the sketch is played. What I think would look nice if the lines connected slowly and gradually to one another. I attempted to work on this issue by adding by only allowing the lines to appear after a certain frame count, however, that only postponed the time of which all the lines appeared simultaneously. I am hoping to edit this soon to create a more smooth-looking environment.

Sketch

Concept

Coding Logic

Challenging Parts

update(magnets) {
    // Update the position of the particle based on magnetic interactions
    let sum = createVector(); // vector that accumulates the magnetic forces

    // iterating through the magnets and calculating the forces they exert on the particle
    for (let magnet of magnets) {
      let diff = p5.Vector.sub(this.pos, magnet.pos); // calculating the vector between particle and magnet
      let poweredDst = pow(diff.x, dstPow) + pow(diff.y, dstPow); // calculating the powered distance, which is used to determine the strength of the force between the particle and the magnet. The higher the poweredDst, the weaker the force.
      let force_mag = (this.power * magnet.power) / poweredDst; // (this.power * magnet.power) determines whether the particle and the magnet attract or repel each other based on their powers. If they have opposite powers, they will attract , and if they have the same powers, they will repel. (this.power * magnet.power) / poweredDst calculates the force magnitude by considering the power and distance. A larger poweredDst results in a weaker force.
      diff.mult(force_mag);
      sum.add(diff); // accumulating the forces.Adds the current force to the cumulative force. Since multiple magnets can affect the particle, and this line accumulates their combined effects.
    }

    this.pos.add(sum.setMag(1).rotate(HALF_PI)); // Update the position based on accumulated forces
  }

challenging part was dealing with the SVG files, as for some reason particles would extend outside the canvas in the exported SVG file, which did not show up in the P5.js sketch. This became complicated as there were no borders and the Pen Plotter would catch the edge of the paper and thus it took a couple of tries to plot the sketch right. I used the version of my sketch that only had the white lines  to export the SVG files. That version of code also had an altered Particle class that saved the previous position and would draw a line between previous and current positions rather than an ellipse at a current position.  (I removed the SVG code from the sketch so that the code runs faster, but apart from that and the canvas size, nothing else was altered).

Areas for improvement / future work

A feature that I would implement next would be giving the magnets some movement. I believe it would make the sketch more dynamic, and it would be interesting to observe how the particle movement would change when the magnets would move versus what it is now when they are static. From aesthetic perspective, it would have been interesting to experiment with light, perhaps adding some glow to the magnets or the particles when they collide with magnets. Combining that with a bit of shading or fading perhaps would give the sketch some depth and make it appear more 3D.

Concept 🧠

“Generative Artistry” is a project that seamlessly transitions from an interactive Pac-Man-inspired game to a mesmerizing display of generative art. This transition serves as a metaphor for the creative process itself, highlighting the unpredictable and varied approaches artists take to contribute to a shared vision. The project simulates the collaborative work of artists, with each “artist” independently contributing to the creation of a shared artwork.

Artistic Vision 🎨

Inspiration 💡

The inspiration for this project was to explore the idea of how multiple artists, each with their own unique style and perspective, can collaborate to create a shared artwork. The project draws inspiration from the chaos and unpredictability of artistic creativity and how individual contributions can come together to form a cohesive whole. The use of randomness, metaphor, and progressive revelation in the project aims to engage users and make them part of this creative journey.

Research 🔍

Initially I had an issue where every artist was working independently and the final outcome was quite messy and random, so I had to tweak the randomness part and researched how to make the each individual part to be relatively close. This led me to the topic of image convolution (8 neighbouring artists influence the 9th artist so that eventually the art doesn’t loose the original silhouette).

Coding Translation and Logic 🔄

The project was meticulously planned to create a seamless transition from the Pac-Man game to generative art. The main challenge was coordinating the actions of individual “artists” (represented by circle balls) to ensure that their movements and colors contribute to the overall artwork.

Coding Logic 💻:

• The Pac-Man game is created with user control of a red ball using arrow keys.
• Yellow balls move randomly, adding unpredictability.
• Once all yellow balls are consumed, the game transitions to generative art.
• The generative art canvas is populated with circle balls that move unpredictably.
• Each walker looks looks for 8 neighbouring colors to have the same scale of color for current pixel in the canvas.
• Each circle ball represents an “artist” and leaves a trail of colors behind.
• The collective movement and colors gradually form a shared artwork.

Coding Snippet 📝:

// Code snippet for handling the transition from game to generative art
if (pacManEaten) {
  // Transition to generative art
  gameState = "art";
  initializeArtists();
}

// propogated rgba color value for given pixel that depends on color of neighbouring pixels
let color = [0, 0, 0, 0];
neighbors.forEach((neighbor) => {
  // pixel values of neighbour pixel
  let pixelColor = img.get(neighbor[0], neighbor[1]);
  // randomizing and color transformation
  if (!this.targetKnown) {
    // in case there is no given target image, then abstract colors
    color[0] += pixelColor[0] + random(-20, 50);
    color[1] += pixelColor[1] + random(-20, 50);
    color[2] += pixelColor[2] + random(-20, 50);
    color[3] += pixelColor[3] + random(-20, 50);
  } else {
    // in case there is a given target image
    color[0] += 255 - pixelColor[0] + random(-20, 50);
    color[1] += 110 - pixelColor[1] + random(-20, 50);
    color[2] += 200 - pixelColor[2] + random(-20, 50);
    color[3] += pixelColor[3] + random(-20, 50);
  }
});
// max rgba color values among neighbouring pixels; it is needed to map the pixel color to 255 range because each rgba value is a sum of neighbours
let maxColor = [0, 0, 0, 0];
neighbors.forEach((neighbor) => {
  let pixelColor = img.get(neighbor[0], neighbor[1]);
  let overall = pixelColor[0] + pixelColor[1] + pixelColor[2];
  let maxOverall = maxColor[0] + maxColor[1] + maxColor[2];
  // tracking the max pixel color
  if (overall > maxOverall) {
    maxColor = [pixelColor[0], pixelColor[1], pixelColor[2], pixelColor[3]];
  }
});
color = color.map((c, index) => {
  // mapping the rgb color to 255 range and mapping alpha to 0-1 range
  if (index === 3) return constrain(c / neighbors.length, 0, 1);
  return Math.floor(constrain(c / neighbors.length, 0, 255));
});

Pen plotter sketch ✏️:

Demo 📺

Link to source code

Challenges 🏋️‍♂️🔥:

• Coordinating independent movements of the “artists” to create a cohesive artwork.
• Implementing a system where each artist’s color and movement are influenced by its neighboring artists.
• Creating a smooth transition between the game and generative art phases.

Proud Moments 😊🏆:

• Successfully achieving coordination among individual artists, creating a shared vision.
• Utilizing kernel operations on image matrices to ensure that artists’ colors are influenced by their surroundings.
• Tweaking different colors.

Pen Plotting Translation 🔄

Pen plotting was utilized to create a physical representation of the generative artwork. The code had to be adapted to accommodate for plotting, taking into consideration factors such as pen movement, paper size, and ink color.

Pen Plotting Process 🏭:

1. The generative art canvas was scaled to fit the plotting paper size.
2. Pen movements were synchronized with the movements of the “artists” on the canvas.
3. Special attention was given to adjusting the line weight and color to achieve the desired physical output.
4. In order to generate more aligning SVG files, I reduced the number of walkers so that less noise and less trace is left on the canvas.
5. To make the plotting more visually appealing, I layered the same SVG on top of itself and moved a bit to sides to create a glitch effect, drawing each layer with different colors.

Areas for Improvement and Future Work 🔍📈🔮

While the project successfully demonstrates the collaborative aspect of generative artistry, there is always room for improvement and expansion:

1. Collaborative Interaction: Enhance the collaborative interaction among “artists,” allowing them to influence each other’s movements and colors more dynamically.
2. User Engagement: Implement additional interactive elements to engage users during both the game and generative art phases.
3. Visual Enhancements: Experiment with different visual effects and techniques to create even more stunning generative artwork.
4. Extended Metaphor: Develop the metaphor of the creative process further to provide users with a deeper understanding of the art-making journey.
5. Expand Plotting: Explore the possibility of creating physical artworks with more complex pen plotting techniques, potentially incorporating new media or materials.

Overall, “Generative Artistry” provides a captivating experience that can be further developed and expanded to explore the depths of collaborative art creation and user engagement.

Other projects developed 🏗️📋

Inspiration:

My original inspiration for this project was Mandalas, they are intricate geometric designs that radiate out from a central point. In many cultures, they’re used for spiritual symbols, meditation aids, or just as beautiful artworks. Mandalas fascinate me with their mix of complexity and simplicity, order and chaos. Through this project, my goal was to merge generative art with Mandalas. I aimed to create an entrancing and visually aesthetic piece of generative art.

First Iteration:

I had really wanted to use the WEBGL library to create 3D sketches. My first attempt at this idea was to overlay many geometric shapes on top of each other in a 3D environment, while zooming in and out of the center, and manipulating the depth between the layers to create an infinite tunnel effect simulating a mandala.

Challenges in SVG Adaptation:

Adapting the original WEBGL 3D sketch to SVG for printing presented some difficult challenges. There’s an incompatibility between the WEBGL and SVG libraries as the field used for SVG in Createcanvas() was also occupied by WEBGL so it was impossible to capture SVG through p5. Even attempting a workaround, such as converting a screenshot of the sketch from PNG to SVG, proved unsuccessful. The intricate details, especially in the inner sections of the design, were lost and impossible to capture using this method. So I decided to create a 2D variation that incorporated similar concepts to the original which was the creation of mandalas using predefined shapes which were randomly picked and overlaid on top of each other.

While this method did yield usable SVG files, they were not satisfying creatively. I felt that I did not utilize any generative concepts in my project. So I decided to start over again and make a new sketch.

Pivoting from the Original Sketches:

My initial design was based on predefined shapes, which limited the generative potential. I did some more research into how to recreate mandalas in p5js and discovered the concept of axes of symmetry in combination with Perlin noise and Vectors which we took in class, both of which opened up a lot more possibilities for the project.

Research Sources:

• Guide on making a kaleidoscope: https://www.youtube.com/watch?v=KcHqRAM0sEU
• Guide on how to make a snowflake design in p5js: https://www.youtube.com/watch?v=R3C2giDfmO8

Code that I am proud of:

class Flower {
  constructor(x, y) {
    this.pos = createVector(x, y);
    this.symmetry = int(random(maxaxis, maxaxis+1));
    this.angle = 360 / this.symmetry;
    this.xoff = random(0, 1000);
    this.yoff = this.xoff + offset;
    this.mx = map(noise(this.xoff), 0, 1, -width*0.6, width*0.6);
    this.my = map(noise(this.yoff), 0, 1, -height*0.6, height*0.6);
    this.px = this.mx;
    this.py = this.my;
    this.timer = 0;
  }

  update() {
    this.px = this.mx;
    this.py = this.my;
    this.mx = map(noise(this.xoff), 0, 1, -width*0.8, width*0.8);
    this.my = map(noise(this.yoff), 0, 1, -height*0.8, height*0.8);
    this.xoff += increment;
    this.yoff += increment;
    this.timer++;

    if (this.timer % 100 === 0) {
      increment = random(0.01, 0.02);
      this.symmetry = int(random(maxaxis, maxaxis+1));
      this.angle = 360 / this.symmetry;
    }
  }

The X and Y  axis movement is gotten from Perlin noise. An offset value is required to be added to x or y offset so that the output is a straight line. The timer variable is used in the SVG sketch to stop the drawing so that it can be saved as an SVG. In update() it saves the previous x and y positions so that a line can be drawn between the current and previous points. x and y offset is then incremented to continue moving the line.

let sw = 2;
strokeWeight(sw);
for (let i = 0; i < this.symmetry; i++) {
  rotate(this.angle);
  line(this.mx, this.my, this.px, this.py);
  push();
  scale(1, -1);
  line(this.mx, this.my, this.px, this.py);
  pop();
}
pop();

This loop runs for each axis of symmetry. With each iteration of the loop, it rotates the canvas by this angle, ensuring that the lines are drawn evenly spaced around the central point. scale() then flips the y-coordinate for mirroring.

The following is the SVG version of the Sketch:

This worked well for the pen plotter and yielded a very cool and intricate-looking pen plot:

Final Steps:

While the initial SVG version yielded very cool results for the pen plotter, it still lacked that entrancing effect that I was seeking to create in the original sketch. So I decided to experiment with the parameters of the sketch. Instead of the timer being used to stop the drawing, I repurposed it to change the axes of symmetry and other variables such as the offset and color.

From my experimentation, the offset dictates how flowy and smooth the lines are. If the offset is high then the lines become more rigid and geometric. By playing around with the ranges of these values, I managed to create a very immersive experience:

To add a final twist to the sketch I decided to add audio into the sketch. My pick was the track named “Can you hear the music” from the movie “Oppenheimer”. The reason I picked this track was because of its gradually increasing tempo and volume which I felt would be ideal to complement the entrancing effect of the sketch. In addition to this track, I again, modified the values and ranges to be based on the volume of the track being played.

let level = amplitude.getLevel();
minaxis = round(map(level, 0, 1, 4, 30))
maxaxis = max(minaxis,maxaxis);
increment = map(level*0.8, 0, 1, 0.0008, 0.3);  // Adjust the range as necessary
offset = map(level, 0, 1, 0, 1000);

By getting the level of amplitude, I can use it to adjust all the values such as the number of axes of symmetry, increment (speed of the lines), and offset (smoothness).

FINAL SKETCH:

FOR FULL EXPERIENCE VIEW THROUGH THIS LINK: GH010625https://editor.p5js.org/mi1171/full/FjZl–Yy4

Possible Future Improvements:

• VR: Due to the nature of this sketch I think that it would be very interesting to port it to VR. I think that It would really enhance the experience and take it to the next level.
• User Interactivity: To make the experience more engaging, we could introduce interactive elements where users can adjust parameters in real time. For example, allowing them to modify the axes of symmetry and color gradients.

Final Thoughts:

The journey of this project, from its initial conception to its final iteration, has been a testament to the iterative nature of design. With each hurdle, I adapted and refined my design, merging traditional Mandalas with modern generative techniques.  Each challenge and pivot brought about new insights and perspectives, ultimately leading to a richer, more dynamic end product and I am very happy with how it ended up looking.

Inspiration

My inspiration for this project arises from both my profound fascination with astronomy and another course I am enrolled in this semester, titled “Astronomy and Cosmology: From Big Bang to the Multiverse.” While studying the Sun in this class, including its composition, origin, magnetic fields, and the nuclear reactions that fuel its ability to emit enough energy essential for life on Earth, I decided to base my midterm project on the most important source of energy for humanity, the Sun.

During my research, I found a captivating visualization video from NASA’s Goddard Space Flight Center.

This video provides various visualizations of the Sun from different angles, as observed from the Earth. While the visuals are striking, there are several intriguing phenomena at play. What we witness in the video is the Sun’s Photosphere, often referred to as its surface. Here, something remarkable happens. The Sun, primarily composed of Hydrogen (H) and Helium (He), has a complex and large magnetic field. Sometimes, these magnetic fields breach the surface, giving rise to what we know as sunspots. These sunspots are regions on the Sun’s surface, usually dark spots, caused by exceptionally strong magnetic fields. They appear darker than their surroundings due to their lower temperature, a result of the magnetic field hindering the flow of heat.

Furthermore, due to the Sun’s absence of a solid structure and its composition of gaseous matter, different regions of the Sun rotate at varying speeds. For instance, the equatorial areas of the Sun complete a full rotation in approximately 24 days, whereas the polar regions take more than 30 days to complete a full rotation. Consequently, these variations in rotation make it appear like clouds composed of various gases are moving at different speeds. Also, the presence of solar flares and solar prominences adds to the spectacle. They create ring-like structures on the Sun’s surface, further enhancing its mesmerizing beauty and complexity.

There are many things to consider, but I decided on taking a few important things for my version of the visualization for a generative art project.

1. The illusion of the movement of gases on the Surface
2. Energy flowing along the magnetic fields of the Sun
3. The ring-shaped Solar Prominence

Note: Although it is an injustice to the Sun to visualize it in 2D, I would like to point out the complexities of being able to encompass everything about the Sun in a relatively shorter time frame compared to hundreds of years of Astronomic research.

Results

Here’s a plotter version of the Sketch. I like this one better, although more work went into building the version above.

https://editor.p5js.org/ap6178/sketches/TrC9XCiJk

Steps

1. At first I did some research on how I could visualize the phenomenas described above. I found a helpful video by Daniel Shiffman from The Coding Train. This video describes Perlin Noise and Flow Fields, which is quite useful in creating the movements of the particles along the Sun’s complex magnetic fields.
2. Here are a few screenshots of the development process:

Coding

The most important part for me in the beginning was to be able to create the 3 phenomenas mentioned above: the surface, flowing particles, and the rings.

I have created two classes: Mover and Rings, and rest of the logic remains on the sketch file. Each item that creates a trailing line is a Mover. 6000 movers are put into the sketch first then a vector field is created. These movers move on the vector field (also called flow field). Whenever a mover is near to a vector in the vector field, which, by the way, are rotating continuously using Perlin Noise to change directions, it gets ejected using the direction and magnitude of the vector it comes across. And adding an illusion of trailing using alpha values in the colors, as well as adding blur and shadows, make it feel like hot gases are flowing in the vector field.

For the surface, I am getting pixel values of the whole sketch using loadPixels() and for each pixel, I am setting an alternating yellow and orange colors along with randomized alpha values. This makes it appear like hot gas clouds are moving on the surface.

What was challenging?

The rings. I tried and scraped so many ideas on creating the rings, but eventually agreed on doing what’s seen on the sketch. The rings are arcs, placed elegantly using ellipse properties, but also containing blur, shadows, and alpha values.

Here’s what I wrote after quite a lot of experimentation:

display() {
    // draw the ring if frameCount is greater than 240
    if (frameCount > 240) {
      // set ring properties: no fill, shadow color, and shadow blur
      noFill();
      drawingContext.shadowColor = color(254, 231, 4, 2);
      drawingContext.shadowBlur = 20;

      // choose a random stroke color from the colors array
      stroke(random(10) > 5 ? this.colors[0] : this.colors[1]);

      // draw an arc with varying parameters
      arc(
        this.pos.x + this.offsetX,
        this.pos.y + this.offsetY,
        -this.a * 1.5,
        -this.b * 1.5,
        (PI / noise(this.pos.x)) * 10,
        PI - 10 * (frameCount % 100)
      );
    }
 }

Pen Plotting

To be able to plot using the Plotter, I had to remove all opacity related variations from the code. As the plotter would plot everything in full opacity, there was no point of adding them on the sketch. Therefore, I made many changes.

1. Removed opacity-related code.
2. Removed the background (the Surface of the Sun as it was mainly playing with alpha values for the cloud-like behavior)
3. To create an optimized SVG file, I updated the code so that the trails are created using lines, not vertices. This is because the plotter would only draw lines from one point to the other.
4. Made it such that the color for each trail changes in between. Each trail would be composed of two colors based on random decisions in between the trail.

Pen Plotted Photo

Timelapse Video of Pen Plotting

Concepts taken from the Course

1. Randomness
2. Noise
3. Vectors
4. Velocity
5. Acceleration
6. Force

Future Work

1. I would love to work more on the rings. I think it has a lot of potential if executed correctly.
2. I would also like to use this sketch as a texture for a sphere drawn in 3D space. This would make it look actually like the Sun.
3. Luminosity is also something that can look really good if done correctly.

Thank you for reading the post!

https://editor.p5js.org/as13805/full/ZG70leVbF

The sketch appears to draw inspiration from the iconic sci-fi movie, Tron. Tron, released in 1982, is known for its distinctive visual style characterized by neon-colored, grid-like landscapes and futuristic aesthetics. The sketch’s terrain generation with lines and triangles resembling a digital grid resonates with the world inside Tron’s computer system. The use of a dark, black background, along with the bright, neon-like stars and the red attractors, strongly evokes the movie’s signature color scheme. This is meant to instill nostalgia in the movie’s viewers.

Tron aesthetic:

The code is organized to create a visually appealing 3D scene with a grid-like terrain, moving stars, and potentially moving attractors. The use of Perlin noise for terrain generation adds a dynamic and abstract element to the sketch. Object-oriented programming is employed to encapsulate and manage different elements, making the code more structured and readable.

Screengrab:

Hand Sketch

Pen Plotter sketch

Since this sketch uses webGL I could not use the SVG export code. Hence I resorted to a screenshot which i converted to SVG in inskscape. I made two changes in order to accommodate for the plotter format. First I reduced the number of rows and columns which effectively reduced the vertices of the sketch and in turn lowered the complexity. I also increased the x.off and y.off values which made the terrain more turbulent. This was to compensate aesthetically for the lower vertex count.

Pen Plotter timelapse:

Future improvements:

I want to make the experience more immersive by allowing the sure to control the camera angles, thereby letting them traverse the terrain on their own at any POV.

I also want to apply textures to the terrain. Instead of a plain grid, I can use textures to make it look like an alien landscape, a digital city, or any other thematic environment.

I also learnt a lot from the video below:

https://youtu.be/_Tyhfpxwips
